high temprature winding wire upto 260 degree centigrade/magnetic wire

Name: high temprature winding wire upto 260 degree centigrade/magnetic wire
Brand: Ghaziabad Flopol Insulation Pvt. Ltd.
Price: 100 INR
Availability: InStock

Price 100 INR/ Meter

Get a Price/Quote

high temprature winding wire upto 260 degree centigrade/magnetic wire Specification

No Of Core
Single core

Connector Type
None; bare ends

Cable Length
Custom as per requirement

Temperature
Up to 260C

Conductor Type
Single Solid or Stranded

Product Type
High Temperature Winding Wire / Magnetic Wire

Material
Copper

Function
Conduct electricity in high-temperature environments

Usage
Winding coils in motors, transformers, generators

Voltage Surge
Up to 1200 V

Frequency (MHz)
DC to 400 MHz

Rated Voltage
600 V - 1000 V

Rated Current
Depends on wire gauge; typically 0.5A to 30A

Cable Capacity
As per standard wire gauge

Insulation Material
Polyimide, PTFE, or Class H/F enamel

Conductor Material
Annealed Copper

Length
Available in 100m, 500m, or custom lengths

Size
0.1 mm to 2.5 mm diameter

Color
Standard: Red, Custom colors available

Diameter
0.1 mm to 2.5 mm

Application
High-temperature environments, motor and transformer winding

Packaging Type
Spools or coils

Thermal Class
Class 155C (F), 180C (H), and up to 260C

Flexibility
High; suitable for tight winding radii

Specific Gravity
Approx. 8.9 g/cm3

Tensile Strength
Above 200 N/mm2

Elongation at Break
20%

Adhesion Test
Passes standard mandrel wrap

Dielectric Strength
Excellent, suitable for critical insulation

Resistance to Chemicals
Resistant to solvents, oils, and varnishes

Surface Finish
Smooth, uniform enamel coating

Breakdown Voltage
Minimum 6 kV/mm

high temprature winding wire upto 260 degree centigrade/magnetic wire Trade Information

Minimum Order Quantity
100 Meter

Main Domestic Market
All India

About high temprature winding wire upto 260 degree centigrade/magnetic wire

We, GHAZIABAD FLOPOL INSULATION PVT. LTD. have created a strong hold in the market as a reliable Manufacturer, Exporter and Supplier of PTFE Cables and Wires. Established in the year 1987, we are engrossed in offering a wide gamut of quality tested Heating Wire, Heat Tracer Wire, PTFE Bonded Cable, PTFE Insulated Cables and PTFE Insulated Wire.

Engineered for Extreme Temperatures

Designed to perform in environments with temperatures reaching up to 260C, our winding wires are the go-to solution for high-stress applications in electrical motors, generators, and transformers. The use of high-grade insulating materials delivers both thermal endurance and superior electrical insulation.

Outstanding Electrical and Mechanical Performance

Boasting a dielectric breakdown voltage of at least 6 kV/mm, our magnetic wires offer remarkable protection against electrical surges and ensure the safety and efficiency of your devices. With a tensile strength above 200 N/mm2 and excellent elongation at break, these wires retain integrity even under mechanical stress.

Versatile and Chemical-Resistant Construction

Our wires feature a smooth, uniform enamel coating and exceptional resistance to solvents, oils, and varnishes. This reliability positions them perfectly for environments where exposure to harsh chemicals is unavoidable, while their flexibility makes them suitable for intricate winding requirements.

FAQ's of high temprature winding wire upto 260 degree centigrade/magnetic wire:

Q: How are these high temperature winding wires suited for demanding applications?

A: These wires are constructed with premium annealed copper and insulated using advanced materials such as Polyimide and PTFE, allowing them to withstand temperatures up to 260C while maintaining excellent dielectric strength. Their robust design ensures safety, dependability, and longevity in motors, transformers, and similar critical devices.

Q: What insulation materials are used and what are their thermal classes?

A: Our winding wires use insulation materials like Polyimide, PTFE, and high-class enamel, ensuring superior thermal performance. The wires are thermally rated for Class 155C (F), 180C (H), and up to 260C, catering to various high-temperature requirements.

Q: When should you choose this wire over standard winding wire?

A: Opt for these high temperature wires when your application involves high ambient heat, frequent voltage surges, or exposure to harsh chemicals-conditions where standard wires would degrade. They are especially recommended for use in heavy-duty and industrial-grade electrical devices.

Q: Where can these wires be installed and used effectively?

A: These wires excel in demanding environments such as motor and transformer windings, generator coils, industrial heating equipment, and locations where both thermal stability and critical insulation are needed. They are suitable for applications across a range of industries.

Q: What benefits do the smooth enamel coating and flexibility provide?

A: The smooth, uniform enamel coating ensures reliable insulation, reduces the risk of shorts, and allows for tight, compact coil windings. High flexibility makes the wire ideal for applications with tight winding radii, minimizing the risk of insulation cracking or conductor fatigue.

Q: How are the wires tested for quality and performance?

A: Each wire undergoes rigorous adhesion tests using standard mandrel wraps, as well as tensile and elongation testing. Electrical tests, including breakdown voltage and dielectric strength measurements, verify their suitability for high-stress applications.
