PTFE Ev wire

Price 100 INR/ Meter

Get a Price/Quote

PTFE Ev wire Specification

Temperature
-65C to +260C

Connector Type
Plain Ends or Custom Connectors

No Of Core
Single Core (multi core available upon request)

Cable Length
Custom as per order / Standard 100m

Conductor Type
Stranded

Product Type
PTFE EV Wire

Material
PTFE (Polytetrafluoroethylene)

Function
Electric Power Transmission and Insulation

Usage
Used for wiring in electric vehicles, batteries, and high-performance circuits

Voltage Surge
Up to 3 kV

Frequency (MHz)
DC to 50 MHz

Rated Voltage
600V - 1000V

Rated Current
According to conductor size, typically 10A - 30A

Cable Capacity
High dielectric strength, withstands high loads

Insulation Material
PTFE

Conductor Material
Tinned Copper

Length
Available in customized lengths, standard 100m rolls

Size
0.5 sq.mm to 16 sq.mm

Color
Blue, Red, Yellow, Black, Green (customizable)

Diameter
1.2mm to 15mm

Application
Electric Vehicle Wiring, High Temperature, Chemical Resistance Applications

PTFE Ev wire Trade Information

Minimum Order Quantity
100 Meter

Main Domestic Market
All India

About PTFE Ev wire

We, GHAZIABAD FLOPOL INSULATION PVT. LTD. have created a strong hold in the market as a reliable Manufacturer, Exporter and Supplier of PTFE Cables and Wires. Established in the year 1987, we are engrossed in offering a wide gamut of quality tested Heating Wire, Heat Tracer Wire, PTFE Bonded Cable, PTFE Insulated Cables and PTFE Insulated Wire.

Exceptional Safety and Durability

Offering self-extinguishing flame retardancy, high dielectric and tensile strengths, and outstanding resistance to oil, chemicals, abrasion, and UV rays, this PTFE EV wire ensures reliable performance even in the most demanding environments. Its robust construction guarantees a secure and long-lasting wiring solution for electric vehicle applications.

Engineered for Versatility and Compliance

Manufactured with RoHS and REACH compliance, and adhering to UL, IEC, and ISO standards, this wire suits a variety of applications beyond electric vehicles. Its broad size, color, and connector options, together with customizable lengths, meet diverse installation needs in industrial, automotive, and outdoor settings.

FAQs of PTFE Ev wire:

Q: How does the PTFE EV wire ensure flame retardancy and safety?

A: The PTFE EV wire features a self-extinguishing insulation that meets stringent UL and IEC flame retardant standards. In the event of fire exposure, the insulation helps prevent flame propagation, enhancing safety in critical EV and industrial settings.

Q: What benefits does PTFE insulation provide in electric vehicle wiring?

A: PTFE insulation offers excellent chemical, oil, and UV resistance along with a high dielectric strength of 20 kV/mm. This ensures reliable power transmission, minimal insulation wear, and suitability for both indoor and harsh outdoor use.

Q: Where is this PTFE EV wire commonly used?

A: This wire is widely employed in electric vehicle wiring, battery connections, and high-performance circuits. Its durability and resistance properties make it suitable for automotive, industrial, and other demanding electrical applications.

Q: What is the process for ordering customized lengths and configurations?

A: Customers can specify their required conductor size, color, cable length (standard or customized), core type (single or multi-core), and connector preferences. Orders are fulfilled accordingly, ensuring compatibility with your unique project requirements.

Q: When is this wire recommended over standard EV wiring?

A: PTFE EV wire is ideal when resistance to extreme temperatures (-65C to +260C), chemicals, oil, abrasive conditions, and UV exposure is essential. It is particularly suitable for environments where enhanced safety and durability are critical.

Q: How does the high dielectric strength benefit the application?

A: With a dielectric strength of 20 kV/mm, the wire offers superior insulation, minimizing the risk of electrical breakdown and ensuring safe operation at high voltages up to 1,000V for electric vehicles and industrial equipment.
