FEP- Almyler-FEP

Name: FEP- Almyler-FEP
Brand: Ghaziabad Flopol Insulation Pvt. Ltd.
Price: 100 INR
Availability: InStock

Price 100 INR/ Meter

Get a Price/Quote

FEP- Almyler-FEP Specification

Cable Length
100m to 305m

Temperature
-60C to +200C

Connector Type
None (bare cable)

No Of Core
Single or Multi-core

Conductor Type
Stranded

Product Type
FEP-Almyler-FEP Cable

Material
FEP (Fluorinated Ethylene Propylene), Almyler

Function
Electrical insulation and conduction

Usage
Industrial and electronic applications

Voltage Surge
Up to 600V

Frequency (MHz)
DC to 60 MHz

Rated Voltage
300V

Rated Current
As per cable gauge specification

Cable Capacity
Standard per size and design

Insulation Material
FEP

Conductor Material
Tinned Copper

Length
100 meters (standard roll)

Size
Custom sizes available

Color
Transparent or as per request

Diameter
As per requirement (typically 1.5mm - 10mm)

Application
Data, signal and instrumentation cable

Toxicity
Low smoke, non-toxic

Surface Finish
Smooth, glossy

RoHS Compliance
Yes

Flame Retardant
Yes, self-extinguishing

Resistance
Excellent chemical and UV resistance

Dielectric Strength
20 kV/mm

Shielding
Optional Almyler polyester foil

About FEP- Almyler-FEP

Experience superb performance with FEP-Almyler-FEP cables featuring unmatchable flame retardant properties and first-string dielectric strength (20 kV/mm). Engineered for industrial and electronic applications, these cables assure low toxicity and excellent chemical and UV resistance. Choose from single or multi-core options, custom sizes, and shielding with Almyler polyester foil. Compliant with RoHS directives, each cable delivers smooth, glossy durability up to 200C. Shop now with our cost-effective, competitive pricing, and secure the best value for your data, instrumentation, and signal needs. Available in standard 100m rolls with transparent or customizable colors, supplied across India.

Versatile Commercial Applications and Application Method

FEP-Almyler-FEP cables excel in commercial environments, providing unmatchable reliability for both specific and general-purpose electrical insulation and conduction. Ideally suited for data, signal, and instrumentation transmission in industrial set-ups, the cable's self-extinguishing nature ensures enhanced safety. Installation is straightforward-apply as per cable gauge and operating requirements. Its robust construction and shielded options protect sensitive electronics while maintaining versatility for a variety of applications.

Sample Orders, Flexible Payment, and Reliable Delivery

Evaluate your requirements with sample orders of FEP-Almyler-FEP cables before full valuation and order completion. Multiple payment terms are accepted, providing flexibility for commercial purchases. FOB ports within India facilitate secure shipping and timely delivery, ensuring orders are handled efficiently from placement to arrival. Count on dependable logistics and transparent communication throughout the supply chain process for peace of mind and on-schedule project execution.

Conductor	Solid, Multistrand, Thermocouple Grade Materials as per ASTM E230 & ANSI MC 96.1
Insulation	Extruded FEP Insulated
Outer Braiding	Almylar Screen with ATC Drain Wire
Outer Jacket	Extruded FEP Insulated
Operating Temp.	200 DegreeC
Limit of Error	According to ASTM E230/77 / IEC 584
Color Code	According to ANSI MC 96.1

FAQ's of FEP- Almyler-FEP:

Q: How does the FEP-Almyler-FEP cable benefit electrical and electronic applications?

A: The FEP-Almyler-FEP cable offers superb flame retardancy, low smoke emission, and robust UV and chemical resistance, making it ideal for industrial, data, and instrumentation applications where uncompromising safety and durability are required.

Q: What are the standard and customizable features available for this cable?

A: Standard offerings include lengths of 100 meters, stranded or solid tinned copper conductors, and RoHS-compliance. Customization is available for size, color, shielding (Almyler polyester foil), and cable core options (single or multi-core).

Q: Where can these cables be installed for optimal use?

A: These cables are suitable for factory floors, data centers, control panels, and electronic labs, ensuring unmatchable performance wherever reliable signal transmission or electrical insulation is paramount.

Q: What process is followed for sample requests and order placement?

A: You can request a sample for evaluation before confirming your order. Once satisfied, place your order-multiple payment modes and clear terms are offered. Your shipment is securely dispatched from the designated FOB port in India.

Q: How does the cable ensure safety in high-temperature environments?

A: With an operating temperature range up to 200C, excellent flame retardant design (self-extinguishing), and durability against chemicals and UV exposure, this cable delivers unmatched safety and resilience for demanding settings.
