Send InquiryFEP-Polyimide-Copper Screening-FEP insulated
Price 100 INR/ Meter
FEP-Polyimide-Copper Screening-FEP insulated Specification
- Cable Length
- Custom lengths available
- Conductor Type
- Stranded or solid
- No Of Core
- Single and multi-core
- Connector Type
- None (customizable)
- Temperature
- -65C to +200C
- Product Type
- FEP-Polyimide-Copper Screening-FEP insulated Cable
- Material
- FEP, Polyimide, Copper
- Function
- Electrical insulation and signal screening
- Usage
- High-performance electrical and instrumentation cabling
- Voltage Surge
- Up to 2500V
- Frequency (MHz)
- DC to 1000 MHz
- Rated Voltage
- 600V
- Rated Current
- 10A
- Cable Capacity
- Refer to spec sheet
- Insulation Material
- FEP (Fluorinated Ethylene Propylene)
- Conductor Material
- Tinned Copper
- Length
- Custom/As required
- Size
- 0.22 mm2 to 2.5 mm2
- Color
- Transparent, custom colors available
- Diameter
- 1.5 mm to 5.0 mm (varies by specification)
- Application
- Aerospace, military, electronics, data transmission
- Outer Sheath
- FEP jacket
- Test Voltage
- 2500V AC
- Dielectric Strength
- 16 kV/mm
- Chemical Resistance
- Excellent; resistant to most chemicals and solvents
- Bend Radius
- Minimum 10x outer diameter
- Shielding
- Copper screening braid for EMI/RFI protection
- Standards
- Meets UL, MIL, and IEC requirements
- Flexibility
- Very high for tight routing
- Flame Retardant
- Complies with IEC 60332-1
- Water Absorption
- <0.01%
- Weight
- Lightweight, varies by length and size
- RoHS Compliance
- Yes
About FEP-Polyimide-Copper Screening-FEP insulated
| Conductor | Solid, Multistrand, Copper Material (Bare Copper, Nickel Plated Copper, Silver Plated Copper, Tinned |
| Core Insulation | Extruded FEP Insulated |
| Isolator | Polyimide |
| Screening | Copper Screening |
| Outer Jacket | Extruded FEP Insulated |
| Operating Temp. | 200 DegreeC |
| Color Code | According to DIN |
